一次性玉米淀粉餐具的整体结构设计介绍

A manufacturer's disposable corn starch tableware is formed by combining tableware matrix 1 and chopstick box 2, which has a rectangular and semi cylindrical concave cavity 3 on tableware matrix 1. In the middle of the cavity 3, there is a radial slit 4 about 1mm wide starting from the bottom, which is about 10mm away from the upper surface of the tableware matrix. Chopstick box 2 is formed by pairing two special water cups 5 and 6, and the cup mouth plane of the special water cup 5 has a semicircular ear 7 along the radial direction, Its thickness is about 0.5mm, and there is a small circular hole 8 with a diameter of about 3mm in the middle of ear 7. When assembling, when inserting chopsticks box 2 into the semi cylindrical concave cavity 3 on tableware mother 1, the semi circular ear 7 must penetrate through the slit 4, and then use plastic nails 9 to penetrate into the small circular hole 8 on ear 7 and melt and fix it. Then, chopsticks box 2 and tableware mother 1 are tightly connected as a whole.

具体的在一次性玉米淀粉餐具母体1上，有一个宽约50mm，长约200mm的半圆筒形凹腔3，在3的中部约100mm处，从底部经外侧面沿径向开有一条约1mm宽的狭缝4，该狭缝4盘面约10mm止，特制水杯5，下部为圆锥形，上部为圆筒状，宽度约10mm，在杯口平面沿径向外沿处有一个半圆形耳子7，7上有一个直径约3mm的小圆孔8：特制水杯6，下部为锥形，上部为圆筒形，宽度约10mm，圆筒直径略小，可与特制水杯5的圆筒部分轻松套合，则5和6对合而成为一个中部带有耳子7的简形筷子盒2：当将2与1#合时，7从4穿出，再将肖钉9贯入小孔8，并熔化固定，则筷子盒2和餐具母体1就紧密地连接为一个整体——当就餐时，必须破坏性地将耳子7从筷子盒2上撕扯下来，则筷子盒2和餐具母体1才能完全分离，则水杯、筷子、匙子和牙签等食具方可取出使用。正是基于这个破坏性的使用特征，就构成了一次性玉米淀粉餐具简易、明确、且不可逆转的判断标识，确保它只能使用一次！

Specifically, on the disposable corn starch tableware matrix 1, there is a semi cylindrical concave cavity 3 with a width of about 50mm and a length of about 200mm. At the middle of the cavity 3, there is a slit 4 with a width of about 1mm from the bottom to the outer side radially. The slit 4 ends at about 10mm on the plate surface, and a special water cup 5 is made. The lower part is conical, and the upper part is cylindrical, with a width of about 10mm, There is a semicircular ear 7 on the outer edge of the cup mouth along the diameter. There is a small circular hole 8 with a diameter of about 3mm on the surface of the cup. The special water cup 6 has a conical lower part and a cylindrical upper part with a width of about 10mm. The cylindrical diameter is slightly smaller and can be easily fitted with the cylindrical part of the special water cup 5. Then, 5 and 6 are paired to form a simple chopsticks box with ears 7 in the middle. 2: When 2 is combined with 1 #, 7 passes through 4, and then the nail 9 is penetrated into the small hole 8, which is melted and fixed, Then chopsticks box 2 and tableware matrix 1 are tightly connected as a whole - when dining, the ears 7 must be destructively torn off chopsticks box 2, so that chopsticks box 2 and tableware matrix 1 can be completely separated, and utensils such as water cups, chopsticks, spoons, and toothpicks can only be taken out and used. It is precisely based on this destructive usage feature that constitutes a simple, clear, and irreversible identification for disposable corn starch tableware, ensuring that it can only be used once!

玉米淀粉又称玉米淀粉，俗称六谷粉，是一种白色、淡黄色的粉末。

Corn starch, also known as corn starch, commonly known as six grain flour, is a white, light yellow powder.

玉米浸泡在0.3%的亚硫酸盐中，经过粉碎、筛选、沉淀、干燥、研磨和其他工艺制成。

Corn is soaked in 0.3% sulfite and processed through crushing, screening, precipitation, drying, grinding, and other processes.

常见产品含有少量脂肪和蛋白质，吸湿性强，较高可达30%以上。玉米淀粉在许多方面都有重要的用途。

Common products contain a small amount of fat and protein, with strong moisture absorption, up to over 30%. Corn starch has important uses in many aspects.

餐具是一种可生物降解的产品，由玉米淀粉制成，并使用新的生产技术进行加工。它可以在自然条件下自我降解，避免环境污染，并节省石油等不可重复使用的资源。

Tableware is a biodegradable product made from corn starch and processed using new production technologies. It can self degrade under natural conditions, avoid environmental pollution, and save non reusable resources such as oil.

经相关检测部门检测，所有卫生和理化指标均符合相关标准，是餐饮市场广泛使用的“餐具”的理想替代品。玉米淀粉基可生物降解餐具是一种无污染产品，在市场上受到提倡，并得到市场内政策的大力支持，以保障人们的生存和环境保护。

After testing by relevant testing departments, all hygiene and physicochemical indicators meet relevant standards, making it an ideal substitute for the widely used "disinfectant tableware" in the catering market. Corn starch based biodegradable tableware is a pollution-free product that has been advocated in the market and strongly supported by domestic policies to ensure people's survival and environmental protection.
